Wireless Controls and Automation

           Wireless Links                                                                I/O Point-to-Point Monitoring and Control

   Migro Wireless

 No parameterization nor programming required
No Internet, Transparent I/O System
No Third party cell, No monthly fees
You have full control over your own carrier
Power system 12/24VDC solar ready
Real time status feedback from the remote site
Fast installation and easy setup
Standard DIN rail mount 35mm



 ■ 2 Miles (3.km) line-of-sight with Yagi 7 dBi antenna
 ■ Optional Extended range 20km+
  ■ Full duplex bidirectional transmission

 Applications: Field operations, irrigation, PLC remote i/o, lighting, process, pumps, generators, solar systems, water management, plantations, remote monitoring, mobile, security, robots, conveyor control, traffic control, test and research equipment, industrial process, plc extension, gate remote, alarm annunciator, hazardous area remotes, Wire Replacement.




 4 CH 2W   938404


 		 938404  TWO WAY

Bidirectional Wireless
4 Channel I/O Digital

 ■ Set with Master & Slave  Modules
   Operation 433MHZ ISM Band

  2 Way Module Each with:
 ■ 4 Digital inputs, N/O Dry Contact,
 ■ 4 Relay outputs SPST  5A, 240V Pilot duty class 2
 ■ Operation 12 or 24 VDC   Optional 120/240VAC
  ■      Specifications


           938404    $899.99 set

.



4 CH  943408TR

    943408TR   One Way

4 Channel Wireless Control System
■ Set with Transmitter and Receiver
    2 Omni antennas 6 inch
    Operation 433MHZ ISM Band
 ■Transmitter  4 Digital inputs, N/O Dry Contact,
 ■ Receiver  4 Relay outputs SPST 5A, 240V Pilot duty class 2
 ■ Operation 12 or 24 VDC
 ■          Specifications


            943408TR    $599.99 set

Operation in pairs only,
One Transmitter and One Receiver
Up to 16 pairs (frequencies channels per site)



            Antenna Selection ( TWO  are required )






938433  Yagi antenna   12 Element

 433MHz, 14 dBi  5 Mile+
 Impedance 50 ohms  SO239 terminal
 Length: 43", Weight: 3.lb
10Ft Coax Cable w Connectors included
 Please request current price




938455   Yagi Antenna   5 Element Beam
433 MHz, Gain: 9 dBi   3 Mile+
Rating: 150 Watts
Impedance 50 ohms  SO239 terminal
 Vertical   55 degrees, Horizontal  60 degrees
With N female termination
Base Length: 32", Weight: 4.0lb
10Ft Coax Cable w Connectors included
 Please request current price





938432   Yagi antenna    3 Element

433MHz, 7 dBi  1 Mile+
 Impedance 50 ohms  SO239 terminal
Length: 18", Weight: 1.lb
10Ft Coax Cable w Connectors included

938432    $179.99 * ea

      *Two required






Omni base antenna 938450

 433 MHz, Gain: 5 dBi  Rating: 250 Watts
Impedance 50 ohms SO239 terminal
Vertical beam 45 degrees With N female termination
Length: 34", Weight: 3.0lb

10Ft Coax Cable w Connectors included


 Please request current price


938092

 938092


 14" Omni Antenna  short range

433 MHz,  3 dBi  short range line of sight
5ft coax mini cable  SMA

*Two required

938091    $19.99  *ea




Specifications
   Digital  Input / Output
Supply power 12 /24 VDC ±10% @ 600 mA
Inputs N/O Normally open digital dry contact
Outputs Relay contact 5Amp SPST 240V Pilot duty
Output Mode Normal or Retain status
Ambient temp 14° to 140° F (-10° to 60° C)
Ambient RH 5% to 95% RH non condensing
Connection Terminal screws DIN
Response 500 msec full duplex
Weight 5.2 lb (2.40kg)  each unit, 2 and 4 channel
Dimensions w optional
NEMA4 Enclosure		 9"W x 9"H x 4"D (220 x 220 x 100 mm)
   Radio System
Frequency 433 MHz license free industrial ISM Band
Receiver  Digital 16 bit, sensitivity -110 dBm
Configuration DIP switch
Data rate 19.2 KBPS Encoded
Antenna external 50 Ohm  (optional)
Compliance FCC CFR part 15.247 ISM
Digital Transmission Gaussian_frequency-shift_keying
Transmitter channels 16 addresses per system
Transmitter power per FCC Part 15.249,  50mV/m @ 3m
Enclosure Selection Optional NEMA4 selection: Fiber or Metal.


       ■ Transmission range calculator

DISCLAIMER:  Radio control equipment in not to be used in life safety. Radio control systems are subject to applications, environmental and atmospheric conditions,
We are not liable of failures on miss applications, radio black outs or interruption of the transmissions.  Radio Installations shall be performed by a certified professional.
