Contactors
  2020

50 Amp. AC-1, 32 Amp. AC-3

3 Pole  Normally Open (N.O.) contacts 600V

50A. Incandescent, LED or resistive load
 32A. Motor control, 20HP@ 480VAC
Auxiliary contact  1NO/1NC
Power Lug Terminal Capacity AWG # 4

Coil 110/120VAC
Details     Specifications

933210  120VAC $37.99



Definite Purpose FLA 50A
40 Amp  2 Pole,  600 VAC

50A AC-1, 40A. AC-3  600V
Lighting - Refrigeration - HVAC
Dim: 2.75 x 2.0 x 3.0 in (70 x 50 x 75 mm)
Power Lug Terminal Capacity AWG # 2

Coil  24VAC
  Specifications

 942024 Coil 24VAC  $15.99

.


934060

60 Amp.  4 Pole  (Silent Operation)

Normally Open (N.O.) contacts
 For 120/220/277/Rated 400V,


10HP @240V, 20HP @460V
 40A. Ballast, 12KW@ 220VAC
Dimension: 2.2w x 3.3h x 2.5d inch
 63Amp AC-1,  40Amp AC-3
Power Lug Terminal Capacity AWG # 4
Coil 110/120VAC
  Specifications

934060 120VAC  $69.99

  934006




60 Amp. 4 Pole
(Silent Operation)
Normally closed (N.C.) contacts
For 120/220/277/Rated 400V,
40A. Ballast, 7 KW@ 220VAC
63A  AC-1,  40A. AC-3
40A, 24VDC, DC Switching
Power indicator, DIN mount

Dim: 2.2 x 3.5 x 2.5 in (55 x 90 x 70 mm)
Power Lug Terminal Capacity AWG # 4
120VAC coil
 Specifications


934006  120VAC
 $99.99

934024  40A. 24VAC  $119.99


934060A

60 Amp.  4 Pole

(Silent Operation)

Normally Open (N.O.) contacts
 For 120/220/277/Rated 400V,


10HP @240V, 20HP @460V
 40A. Ballast, 12KW@ 220VAC
Dimension: 2.2w x 3.3h x 2.5d inch
 63Amp AC-1,  40Amp AC-3
Power Lug Terminal Capacity AWG # 4
Auxiliary Contact  1 NC /1 NO  5Amp.
Coil 110/120VAC
Specifications      add DIN rail

934060A  120VAC  $99.99

Auxiliary Contact


  934006A

60 Amp. 4 Pole (Silent Operation)
Normally closed (N.C.) contacts
For 120/220/277/Rated 400V,
40A. Ballast, 7 KW@ 220VAC
63A  AC-1,  40A. AC-3
40A, 24VDC, DC Switching
Power indicator, DIN mount

Dim: 2.2 x 3.5 x 2.5 in (55 x 90 x 70 mm)
Power Lug Terminal Capacity AWG # 4

Auxiliary Contact  1 NC /1 NO  5Amp.
Coil 110/120VAC
 Specifications       add DIN rail

934006A  120VAC  $129.99

Auxiliary Contact



dpcontactor

40 Amp.  4 Pole    944120
Normally Open (N.O.) contacts
NEMA 2 Definite purpose

10HP @240V, 15KW 277VAC
40 A. Ballast, 7 KW@ 220VAC
50A AC-1, 40A. AC-3  600V
Lighting - Refrigeration - HVAC

Dim: 2.75 x 3.5 x 3.0 in (70 x 90 x 75 mm)
Power Lug Terminal Capacity AWG # 2

120VAC coil SPECIFICATIONS  Dimensions

944120  120VAC $39.99

944122  220VAC $49.99

944124   24VAC $39.99



40 Amp.    3 Pole    943120
Normally Open (N.O.) contacts
NEMA 2 Definite purpose

10HP @240V, 15KW 277VAC
40 A. Ballast, 7 KW@ 220VAC
50A AC-1, 40A. AC-3  600V
Lighting - Refrigeration - HVAC

Dim: 2.75 x 3.5 x 3.0 in (70 x 90 x 75 mm)
Power Lug Terminal Capacity AWG # 4

120VAC coil

943120  120VAC  $35.99

943024   24VAC  $45.99

943122   220VAC  $45.99



100 Amp. 4 Pole  Slim contactor
Normally Open (N.O.) contacts
For 120/220/277/Rated 400V,
50A. Ballast, 10 KW@ 220VAC, 15KW@277V
100A  AC-1,  40A. AC-3
40A, 24VDC, DC Switching
Power indicator, DIN mount

Dim: 110 x 81 x 68 mm) Dimensions
Power Lug Terminal Capacity AWG # 2/0
120VAC coil

934100 120VAC $199.99



100 Amp. 4 Pole   Slim contactor
Normally closed (N.C.) contacts
For 120/220/277/Rated 400V,
50A. Ballast, 10 KW@ 220VAC, 15KW@277V
100A  AC-1,  40A. AC-3
40A, 24VDC, DC Switching
Power indicator, DIN mount

Dim: 110 x 81 x 68 mm) Dimensions
Power Lug Terminal Capacity AWG # 2/0
120VAC coil

934101 120VAC $299.99




933021 Miniature Contactor
20Amp, 3 Pole, 120VAC Coil
2HP @240V, 7.5HP @460V
1HP @120V,
20Amp AC-1, 12Amp. AC-3
Screw Clamp Terminals, 600V, 1 N.O. Aux.,
AC Coil Current Inrush 32VA, Sealed 6VA
Dim: 1.7 x 2.5 x 2.3 in (45 x 64 x 58 mm)
Power Lug Terminal Capacity AWG #
8



933021 120VAC  $47.99



933020 Miniature Contactor
20Amp, 3 Pole, 12VDC Coil
2HP @240V, 7.5HP @460V
1HP @120V,
20Amp AC-1, 12Amp. AC-3
Screw Clamp Terminals, 600V, 1 N.O. Aux.,
DC Coil Current Inrush/Sealed  250mA
Dim: 1.7 x 2.5 x 2.3 in (45 x 64 x 58 mm)
Power Lug Terminal Capacity AWG # 8

Specifications

933020 12V  $49.99



Transformer 50VA
480/277/240/208VAC  To 120VAC


SPECIFICATIONS

$69.79

DIN rail 20cm (7.87inch)

 $6.00

  Vacuum contactor


35, 60, 100A

 Silent, No acoustical sound, No click, No vibration





Single pole


 3 pole

.
